Image Sensor

Approx. 1/2.8 type CMOS image sensor

Scanning Area

5.57 mm (H) × 3.13 mm (V)
{7/32 inches (H) × 1/8 inches (V)}

Minimum Illumination

Color :
0.007 lx (30IRE, F1.3, 1/30s, AGC:11)*
0.009 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0006 lx (50IRE, F1.3, 16/30s, AGC:11)*

BW :
0 lx (50IRE, F1.3, 1/30s, AGC:11, IR LED: On)
0.006 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0004 lx (50IRE, F1.3, 16/30s, AGC:11)*
*Converted value

White Balance

ATW1 / ATW2 / AWC

Shutter Speed

[60 fps Mode] 1/60 Fix to 1/10000 Fix
[30fps/15fps mode] 1/30 Fix to 1/10000 Fix
[50 fps Mode] 1/50 Fix to 1/10000 Fix
[25fps/12.5fps mode] 1/25 Fix to 1/10000 Fix

Maximum Shutter

[60 fps mode] Max. 1/4000 s to Max. 16/30 s
[50 fps mode] Max. 1/4000 s to Max. 16/25 s
[30 fps mode] Max. 1/4000 s to Max. 16/30 s
[25 fps mode] Max. 1/4000 s to Max. 16/25 s
[15 fps mode] Max. 1/4000 s to Max. 16/30 s
[12.5 fps mode] Max. 1/4000 s to Max. 16/25 s

i-PRO Intelligent Auto

On / Off

i-PRO Super Dynamic

On / Off, The level can be set in the range of 0 to 31.

Dynamic Range

Max.144 dB (Super Dynamic : On, Level 31)

Adaptive Black Stretch

The level can be set in the range of 0 to 255.

Back light compensation / High light compensation

BLC (Back light compensation) / HLC (High light compensation) / Off (only when Super dynamic / Intelligent Auto : Off)

Fog Compensation

On / Off (only when Intelligent auto / auto contrast adjust : Off)

Maximum Gain (AGC)

The level can be set in the range of 0 to 11.

Color/BW (ICR)

Off / On (IR Light Off) / On (IR Light On) / Auto1 (IR Light Off) / Auto2 (IR Light On) / Auto3 (SCC)

IR LED Light

High / Middle / Low / Off,
Maximum irradiation distance : 70 m {Approx. 230 ft} (30IRE) / 50 m {Approx. 164 ft} (50IRE)

Digital Noise Reduction (DNR)

The level can be set in the range of 0 to 255.

Video Motion Detection (VMD)

On / Off, 4 areas available

Scene Change Detection

On / Off, 1 areas available

Audio Detection

On / Off

AI Sound classification

Gunshot, Yell, Vehicle horn, Glass break

AI Analytics

AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection,
AI Vehicle Detection, AI Non mask Detection (prior to V2.70), AI Occupancy Detection, AI Scene Change Detection

Privacy Zone

On / Off, Up to 8 zones available

VIQS

On / Off, Up to 8 zones available

Image rotation

0 ° / 90 ° / 180 ° / 270 °

Camera Title (OSD)

On / Off, Up to 40 characters (alphanumeric characters, marks)

Focus Adjustment

Auto focus / Manual
