COMPONENT

SPECIFICATIONS

Image Sensor

Approx. 1/2.8 type CMOS image sensor

Scanning Area

5.57 mm (H) × 3.13 mm (V) {7/32 inches (H) × 1/8 inches (V)}

Minimum Illumination

Color :
0.007 lx (30IRE, F1.3, 1/30s, AGC:11)*
0.009 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0006 lx (50IRE, F1.3, 16/30s, AGC:11)*

BW :
0 lx (50IRE, F1.3, 1/30s, AGC:11, IR LED: On)
0.005 lx (50IRE, F1.3, 1/30s, AGC:11)
0.0004 lx (50IRE, F1.3, 16/30s, AGC:11)*
*Converted value

White Balance

ATW1/ ATW2/ AWC

Shutter Speed

[60 fps mode]
1/60 Fix to 1/10000 Fix
[30 fps/ 15 fps mode]
1/30 Fix to 1/10000 Fix
[50 fps mode]
1/50 Fix to 1/10000 Fix
[25 fps/ 12.5 fps mode]
1/25 Fix to 1/10000 Fix

Maximum Shutter

[60 fps mode]
Max. 1/4000 s to Max. 16/30 s
[30 fps/ 15 fps mode]
Max. 1/4000 s to Max. 16/30 s
[50 fps mode]
Max. 1/4000 s to Max. 16/25 s
[25 fps/ 12.5 fps mode]
Max. 1/4000 s to Max. 16/25 s

Intelligent Auto

On/Off

Super Dynamic

On/Off (Range : 0 to 31)

Dynamic Range

Max. 144 dB (Super Dynamic: On, Level: 31)

Adaptive Black Stretch

The level can be set in the range of 0 to 255.

Back Light Compensation/High Light Compensation

BLC (Back light compensation) / HLC (High light compensation) / Off (Range : 0 to 31)
*only when Super Dynamic/ Intelligent Auto: Off

Fog Compensation

On/Off (Range : 0 to 8)
*only when Intelligent Auto / Auto contrast adjust: Off

Maximum Gain (AGC)

The level can be set in the range of 0 to 11.

Color/BW (ICR)

Off/ On(IR Light Off)/ On(IR Light On)/
Auto1(IR Light Off)/ Auto2(IR Light On)/ Auto3(SCC)

IR Illumination

High/ Middle/ Low/ Off
Maximum irradiation distance:
70 m {Approx. 230 ft} (30IRE)*
50 m {Approx. 164 ft} (50IRE)
* Converted value

Digital Noise Reduction

The level can be set in the range of 0 to 255.

Video Motion Detection (VMD)

On/ Off
4 areas available

Scene Change Detection (SCD)

On/ Off
1 area available

Audio Detection

On/ Off

AI Sound Classification

Selectable from Gunshot, Yell, Vehicle horn, Glass break

AI Anaytics

AI Video Motion Detection, AI Privacy Guard, AI Face Detection, AI People Detection, AI Vehicle Detection, AI Non mask Detection (prior to V3.30), AI Occupancy Detection, AI Scene Change Detection, AI On-site Learning, Ai Processing Relay

Privacy Zone

On/Off, Up to 8 zones available
Color: gray/white/blue/green/red/black, or mosaic

VIQS

On/Off
Up to 8 zones available

Image Rotation

0° (Off)/ 90°/ 180° (Upside-down)/ 270°

Image Stabilizer

On/Off (Built-in gyro sensor)
Available only in the 30 fps mode

Camera Title (OSD)

On/Off
Up to 40 characters, Up to 2 lines (alphanumeric characters, marks)

Optical Zoom

3.1x (Motorized zoom / Motorized Focus)

Extra Zoom

max 9.3x
(3.1x - 9.3x when resolution is 640x360)

Digital (electronic) Zoom

-

Focal Length

2.9 mm – 9 mm
{1/8 inches – 11/32 inches}

Angular Field of View

[16:9 mode]
Horizontal： 36 ° (TELE) - 114 ° (WIDE)
Vertical： 20 ° (TELE) - 60° (WIDE)
[4:3 mode]
Horizontal： 27 ° (TELE) - 82 ° (WIDE)
Vertical： 20 ° (TELE) - 60° (WIDE)

Maximum Aperture Ratio

1:1.3(WIDE) - 1:2.5(TELE)

Focus Range

0.3 m {11-13/16 inches} - ∞

Aperture Range

F1.3 - close

Safety

UL (UL62368-1), c-UL (CSA C22.2 No.62368-1), CE, IEC62368-1

EMC

FCC (Part15 ClassA), ICES-003 Issue 7 ClassA, EN55032 ClassA, EN55035

Power Source/Power Consumption

[Power Source]
DC12 V, PoE+ (IEEE802.3at compliant)
[Power Consumption]
DC12 V ：1.2 A／ Approx. 14.2 W
PoE+ DC 54 V ：260 mA／ Approx. 14.0 W（Class 4 device）

Ambient Operating Temperature

-10 °C to +50 °C {14 °F to 122 °F}
(Power On range: 0 °C to 50 °C {32 °F to 122 °F})

Ambient Operating Humidity

10 % to 90 % (no condensation)

Shock Resistance

IK10(IEC 62262)

Dimensions

ø129.5 mm × 102.5 mm (H) {ø5-3/32 inches ×4-1/32 inches (H)}
Dome radius 41.5 mm {1-5/8 inches}

Mass (approx.)

Approx. 820 g {1.9 lbs}
